Audio JACK Ø3.5

Ø3.5 Stereo Jack Socket Audio Jack Connector Mono/Stereo

Board mount type audio connector with metal shield.
This product has two types of microphone input (pink color) and audio out (Green color).

Specification:
1.Rating : DC 30V 0.5A;
2.Contact resistance: ≦50mΩ;
After test: ≦100mΩ
3.Insulation resistance: ≧100MΩ(500VDC); After test: ≧50MΩ
4.Withstand voltage: 500VAC ;
5.Insertion and extraction force: 3N~30N;
6.life test: 5000cycles min;
7.Operation temperature range: -20°C~+70°C
8.Preservation temperature range: -40°C~+85°C
