RJ45 1 Port R/A

RJ45 Single Port Right Angle

RJ45 Connector W/TF 1000 Base Tab-down 1x1Port
Board mount type single port RJ45 connector with metal shield right angle type.

Meets or exceeds IEEE 802.3 standard for 10/100/1000 Base-TX 350uH minimum OCL with 8mA Bias current
Available with or without LEDs
Minimum 1500Vrms isolation per IEEE802.3 requirement Operating temperature 0°c to +70°c
Storage temperature -40°c to +85°c
